Body Structure |
Stainless Steel 1.4301 (Optional) |
|
Measurement Tube Material |
316 Stainless Steel |
|
Nominal Diameters |
DN15 - DN150 DIN EN 1092-1 From B ½" ... 12" ASME 16,5 RF |
|
Flange Material |
Alloy Steel ST 37-2 (Standard) I Stainless Steel 1.4301 (Optional) |
|
Nominal Pressures |
DN15-DN150 |
|
Process Temperature |
-20 ... +150 °C PTFE |
|
Internal Lining Material |
PTFE |
|
Measurement Electrode Mat. |
316 Stainless Steel, Hastelloy C22, Tantalum, Titanium, Platinum Rhodium |
|
Grounding Electrode Mat. |
316 Stainless Steel, Hastelloy C22, Tantalum, Titanium, Platinum Rhodium |
|
Grounding Ring |
The grounding ring should be preferred when the pipe material is made of plastic. |
|
Process Conductivity |
? 5 µS/cm |
|
Measurement Speed Range |
0,02 ... 12 m/s |
|
Accuracy |
% 0.2 |
|
Protection Class |
IP67 (Compact Model) / IP68 (Separated Model) |
