Measurable pipe diameter range |
200 ~ 2000 mm |
|
Flow velocity measurement range |
0 ~ 10 m/s; full-scale operating range can be continuously adjusted within 1 ~ 10 m/s |
|
Measurement accuracy |
±1.5% when full-scale flow velocity is > 1 m/s |
|
Conductivity of measured medium |
Must be greater than 50 µS/cm |
|
Operating pressure |
1.6 MPa |
|
Electrode materials |
Molybdenum-containing stainless steel (0Cr18Ni12Mo2Ti), Hastelloy C-276, Titanium
|
|
Measuring tube (liner) material |
ABS |
|
Maximum temperature of measured medium |
60°C for ABS |
|
Enclosure protection class |
IP68 in accordance with GB 08 84 standard |
|
Maximum signal transmission distance between sensor and converter |
50 meters (for special requirements, please contact the manufacturer) |
|
Flowmeter Output Signals |
|
|
DC current: |
0 ~ 10 mA, load resistance 0 ~ 1 k? |
|
Current: |
4 ~ 20 mA, load resistance 0 ~ 500 ? |
|
Frequency:
Connection: |
1 ~ 5 kHz, load resistance 250 ~ 1.2 k?
2” G male thread |
