Features |
Description |
|---|---|
|
Sensing element |
J, K, N, T thermocouple |
|
Process connection |
G1/2 or M20x1,5 thread |
|
Connection head |
Type B |
|
Sheath material |
Stainless Steel 1.4541 |
|
Transmitter |
Temperature transmitter can be mounted in a connection head |
|
Measuring insert |
Pipe or mineral insulated version |
|
Thermowell diameter |
6, 9, 9/6 ,10, 11, 12, 15 |
|
Measuring range |
-40.. +150°C |
|
Length L [mm] |
100/150/200/250/400 |
|
Process connection G |
M20x1,5 / G 1/2 or other |
| Neck length Led | 150 /160 / 250 |
