Description |
|
|---|---|---|
|
Sensing element |
J, K, N, T |
|
|
Measuring range |
-40 ÷ +550°C |
|
|
Process connection |
G1/2, M20x1,5 thread or Flanged (DN15, DN25, ANSI etc.) |
|
|
Connection head |
Type B |
|
|
Sheath material |
Stainless steel 1.4541/316L/316Ti |
|
|
Measuring insert |
1,2 mm – 1,5 mm |
|
|
Thermowell diameter |
9, 10, 11, 12, 14, 15 mm |
|
|
Length L [mm] |
160, 250, 400 mm and other |
|
|
Cable gland |
ATEX II GD IP65 (for cable 5÷10 mm) |
|
|
Swaged Forms |
Ø 12 mm / Ø 9,0 mm swaged |
TEMPERATURE
