Feature |
Description |
|
|---|---|---|
|
-100kPa...0~ 10kPa.. .60MPa(Ceramic Core Transmitter range span ?0.3Mpa) |
|
|
Overload Pressure |
1.5 times of rated pressure |
|
|
Accuracy |
+0.5%F.S,?1.0%F.S |
|
|
Display Mode |
4 digit LCD |
|
|
Working Temperature |
-20~75°C |
|
|
Storage Temperature |
|
|
|
Measured Medium |
Gas or liquid compatibte with 1Cr18Ni9Ti, fluororubber or nitrile rubber; Gas or liquid compatible with S304, 316L, fluororubber or nitrile rubber |
|
|
Two-wired; Three-wired; Four-wired |
|
|
Output Signal |
4~ 20mA; 0-10VDC; RS485 | |
| Power Supply | 12~30VDC | |
| Electrical connection | Big Hirschmann | |
| Enclosure Protection |
|
|
| Pressure Connection | G1/4, NPT1/4,R1/4, M12*1, M10*1, M20*1.5, G1/2 |
PRESSURE
